Ritchey Outback Frameset
Eat Sleep Cycle is a Certified Ritchey Assembler and we can build your Ritchey Outback Frameset to your exact requirements. Simply Contact Us for a quote.
Bikepacking, road, off-road, trail, expedition, you name it…
The Ritchey Outback is designed to do it all.
Tom Ritchey rides about 10,000 miles (16,000 km) per year, and most of that is off-road. Combine that with his more than 40 years of designing and building bicycles, and it’s no wonder the Outback has become an icon in the gritty world of Gravel and Adventure bikes.
The updatet Outback sports several practical and adaptable features that offer riders the ability to chase epic ride experiences beyond the end of the road and the end of the day. Rack and fender mounts help to keep things dry and expand the load-carrying capacity for longer bikepacking adventures, while clearance for 700C x 48 mm or 650B x 2.0 inch tires opens up a whole new world of possibilities. The frame accepts Flatmount disc calipers, and the all-carbon Ritchey Adventure fork with multi-purpose mounts on the legs gives you more places to stow the supplies you gather at the last cafe.
Painstakingly TIG-welded with proprietary triple-butted Ritchey Logic steel tubing, the OUTBACK frame delivers the legendary Ritchey ride quality that’s resilient over the harshest terrain and delightfully responsive when you want to open it up.
Technical details of the OUTBACK Disc Gravel frameset
- wheel / tire compatibility: 700 x 48 mm / 650 x 2.0 inch
- Flat Mount disc brake design
- compatible rotor sizes: 140 / 160 mm
- colour options: Sunset Fade / Guac y Crema (matte green)
Ritchey OUTBACK V2 Disc frame
- material: heat-treated, triple-butted Ritchey Logic steel tubing (TIG welded)
- featuring rack and fender mounts
- 2 bottle mounts
- external cable routing
- ultra-light forged and machined straight 1 1/8″ headtube
- WCS headset (IS42/28.6 | IS42/30)
- front derailleur clamp size: 28.6 mm (max. torque setting: 2.5 Nm)
- crankset / chainring compatibility:
- single chainring: 36 to 46 teeth
- double chainring: all options from 46/30 to 50/34 teeth
- bottom bracket: 68 mm (English threaded)
- 27.2 mm seat tube with integrated seat collar
- O.L.D.: 142 mm (12 mm aluminium thru axle included)
- replaceable stainless-steel derailleur hanger
- weight: 2,175 grams (size L, without thru axle)
Ritchey Adventure Disc fork
- material: carbon
- multi-purpose, rack and fender mounts
- max. payload: 3 kg per side
- 1 1/8″ straight steerer with integrated 45° crown race
- steerer length: 300 mm
- axle to crown: 393 mm
- rake / offset: 50 mm
- O.L.D.: 100 mm (12 mm aluminium thru axle included)
- weight: 446 grams (uncut, without thru axle)
Scope of supply: Outback steel frame incl. Adventure carbon fork
